SEAL;U CUP Doosan D184112

SEAL;U CUP, D184112 для вилочного погрузчика Doosan

Полное описание

Модель техники	D50S2/D60S2/D70S2, G35S/G40S/G45S, D35S/D40S/D45S, D50S/D60S/D70S, D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2, G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2, D20S3/D25S3/D30S3/D32S3/D33S3, G20E3/G25E3/G30E3/G32E3, GC20E3/GC25E3/GC30E3/GC32E3, GC15S2/GC18S2, GC20SC2, D100/D120, D150, G20S3/G25S3/G30S3, GC20S3/GC25S3/GC30S3, BC20S2/BC25S2/BC30S2, BC25SE2, B20S2/B25S2/B30S2, G20P3/G25P3/G30P3/G32P3/G33P3, D50/D60/D70, BC20S/BC25S, BC30S
Номер по каталогу	D184112
Бренд	DOOSAN
Система Doosan	Engine 6 Ton DIESEL, Engine 4 Ton GAS, Engine 4 Ton DIESEL, Engine 2 Ton DIESEL, Engine 2 Ton GAS, Engine 2 Ton GAS CUSHION, Engine 1 Ton GAS CUSHION, Engine 10 Ton DIESEL, Engine 15 Ton DIESEL, Electric 2 Ton CUSHION, Electric 2 Ton PNEUMATIC
Раздел Doosan	CHASSIS, FRONT END

Все характеристики

По запросу

Артикул: ds001136-D184112

Запросить цену

Цена по запросу

0 ₽

Обзор
Характеристики
Отзывы0

Каталожный номер: D184112

Название: SEAL;U CUP

Модель техники: D50S2/D60S2/D70S2, D50S/D60S/D70S, D100/D120, D150, D20S3/D25S3/D30S3/D32S3/D33S3, G20S3/G25S3/G30S3, GC20S3/GC25S3/GC30S3, G35S/G40S/G45S, D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2, D35S/D40S/D45S, D50/D60/D70, BC20S/BC25S, BC30S, BC20S2/BC25S2/BC30S2, BC25SE2, B20S2/B25S2/B30S2, G20E3/G25E3/G30E3/G32E3, GC20E3/GC25E3/GC30E3/GC32E3, G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2, GC15S2/GC18S2, GC20SC2, G20P3/G25P3/G30P3/G32P3/G33P3

Тип техники: Вилочный погрузчик с ДВС, Электропогрузчик / Engine Powered Trucks, Electric Powered Trucks

Система Doosan: Engine 6 Ton DIESEL, Engine 10 Ton DIESEL, Engine 15 Ton DIESEL, Engine 2 Ton DIESEL, Engine 2 Ton GAS, Engine 2 Ton GAS CUSHION, Engine 4 Ton GAS, Engine 4 Ton DIESEL, Electric 2 Ton CUSHION, Electric 2 Ton PNEUMATIC, Engine 1 Ton GAS CUSHION

Раздел Doosan: CHASSIS, FRONT END

Узел Doosan: Chassis, Attachment, Carriage, Mast

Основная схема: TILT CYLINDER GP-2 REQUIRED. Номер на картинке: 5.

Применяемость: найдено 62 применений.

Применяемость по каталогу Doosan

Модель	Серии	Тип	Система	Раздел	Узел Doosan	Схема	Позиция	Кол-во	Примечание
D50S2/D60S2/D70S2	EM0BH, EM0EH \| A130012	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	TILT CYLINDER GP-2 REQUIRED	5	1	J
D50S2/D60S2/D70S2	EM0BH, EM0EH \| A130012	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-P/S	6	2	J
D50S2/D60S2/D70S2	EM0BH, EM0EH \| A130012	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-P/S - (A135004)	8	2	J
D50S2/D60S2/D70S2	EM0BH, EM0EH \| A130012	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-P/S	6	2	J
D50S2/D60S2/D70S2	EM0BH, EM0EH \| A130012	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-P/S	6	2	J
D50S/D60S/D70S	EM0C1 \| A130013	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-P/S	8	2	J
D50S/D60S/D70S	EM0C1 \| A130013	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER - TILT	5	1	J
D50S/D60S/D70S	EM0C1 \| A130013	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	TILT CYLINDER GP-2 REQUIRED	5	1	J
D100/D120	EM083, EM084, EM0F1, EM0F2 \| A141520	Вилочный погрузчик с ДВС	Engine 10 Ton DIESEL	FRONT END	Attachment	CYLINDER,SIDE SHIFT;ATTACHMENT	5	1	J
D150	EM086, EM0F3 \| A142307	Вилочный погрузчик с ДВС	Engine 15 Ton DIESEL	FRONT END	Carriage	CYLINDER,SIDE SHIFT;ATTACHMENT	5	1	J
D20S3/D25S3/D30S3/D32S3/D33S3	EM090, EM0GU \| A211796	Вилочный погрузчик с ДВС	Engine 2 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP	15	2	J
D20S3/D25S3/D30S3/D32S3/D33S3	EM090, EM0GU \| A211796	Вилочный погрузчик с ДВС	Engine 2 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-STEER	15	2	J
G20S3/G25S3/G30S3	EM097, EM099 \| A211798	Вилочный погрузчик с ДВС	Engine 2 Ton GAS	CHASSIS	Chassis	CYLINDER GP	15	2	J
GC20S3/GC25S3/GC30S3	EM094, EM095 \| A211800	Вилочный погрузчик с ДВС	Engine 2 Ton GAS CUSHION	CHASSIS	Chassis	CYLINDER GP	15	2	J
G35S/G40S/G45S	EM0B1, EM0BQ \| A231095	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFL-RH(MFH 3000MM)	6	1	J
G35S/G40S/G45S	EM0B1, EM0BQ \| A231095	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFL-LH(MFH 3000MM)	6	1	J
G35S/G40S/G45S	EM0B1, EM0BQ \| A231095	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFT-RH	6	1	J
G35S/G40S/G45S	EM0B1, EM0BQ \| A231095	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFT-LH	6	1	J
G35S/G40S/G45S	EM0B1, EM0BQ \| A231095	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP - STD-RH	7	1	J
G35S/G40S/G45S	EM0B1, EM0BQ \| A231095	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP - STD-LH	7	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFL-RH(MFH 3000MM)	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFL-LH(MFH 3000MM)	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFT-RH	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFT-LH	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP - STD-RH	7	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP - STD-LH	7	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFT-RH	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFT-LH	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFL-LH	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFL-RH	6	1	J
D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2	EM0C9, EM0E8 \| A231526	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP - STD-LH	7	1	J
D35S/D40S/D45S	EM021, EM0BP \| D150864	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFL-RH(MFH 3000MM)	6	1	J
D35S/D40S/D45S	EM021, EM0BP \| D150864	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFL-LH(MFH 3000MM)	6	1	J
D35S/D40S/D45S	EM021, EM0BP \| D150864	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFT-RH	6	1	J
D35S/D40S/D45S	EM021, EM0BP \| D150864	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP-SECONDARY - FFT-LH	6	1	J
D35S/D40S/D45S	EM021, EM0BP \| D150864	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP - STD-RH	7	1	J
D35S/D40S/D45S	EM021, EM0BP \| D150864	Вилочный погрузчик с ДВС	Engine 4 Ton DIESEL	FRONT END	Mast	LIFT GP - STD-LH	7	1	J
D50/D60/D70	EM023 \| D170122	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-STEER	8	2	J
D50/D60/D70	EM023 \| D170122	Вилочный погрузчик с ДВС	Engine 6 Ton DIESEL	CHASSIS	Chassis	CYLINDER GP-TILT - 2 REQUIRED	5	1	J
BC20S/BC25S, BC30S	EM027, EM028, EM029, EM030, EM031, EM032 \| D270467	Электропогрузчик	Electric 2 Ton CUSHION	CHASSIS	Chassis	CYLINDER GP	15	2	J
BC20S2/BC25S2/BC30S2, BC25SE2	EM0CJ, EM0CK, EM0CL, EM0CM, EM0CN, EM0CP, EM0CQ \| D290559	Электропогрузчик	Electric 2 Ton CUSHION	CHASSIS	Chassis	CYLINDER GP	15	2	J
BC20S2/BC25S2/BC30S2, BC25SE2	EM0CJ, EM0CK, EM0CL, EM0CM, EM0CN, EM0CP, EM0CQ \| D290559	Электропогрузчик	Electric 2 Ton CUSHION	CHASSIS	Chassis	CYLINDER GP-STEER	7	2	J
B20S2/B25S2/B30S2	EM0B8, EM0B9, EM0BA, EM0BB, EM0BC, EM0BD \| SB1003	Электропогрузчик	Electric 2 Ton PNEUMATIC	CHASSIS	Chassis	CYLINDER GP	15	2	J
B20S2/B25S2/B30S2	EM0B8, EM0B9, EM0BA, EM0BB, EM0BC, EM0BD \| SB1003	Электропогрузчик	Electric 2 Ton PNEUMATIC	CHASSIS	Chassis	CYLINDER GP-STEER	15	2	J
G20E3/G25E3/G30E3/G32E3	EM0CW, EM0CX, EM0DX, EM0G9, EM0GA \| SB1008-00	Вилочный погрузчик с ДВС	Engine 2 Ton GAS	CHASSIS	Chassis	CYLINDER GP	15	2	J
G20E3/G25E3/G30E3/G32E3	EM0CW, EM0CX, EM0DX, EM0G9, EM0GA \| SB1008-00	Вилочный погрузчик с ДВС	Engine 2 Ton GAS	CHASSIS	Chassis	CYLINDER GP-STEER	15	2	J
GC20E3/GC25E3/GC30E3/GC32E3	EM0CU, EM0CV, EM0DY \| SB1009	Вилочный погрузчик с ДВС	Engine 2 Ton GAS CUSHION	CHASSIS	Chassis	CYLINDER GP	15	2	J
GC20E3/GC25E3/GC30E3/GC32E3	EM0CU, EM0CV, EM0DY \| SB1009	Вилочный погрузчик с ДВС	Engine 2 Ton GAS CUSHION	CHASSIS	Chassis	CYLINDER GP-STEER	7	2	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFL-RH(MFH 3000MM)	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFL-LH(MFH 3000MM)	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFT-RH	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFT-LH	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP - STD-RH	7	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP - STD-LH	7	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFT-RH	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFT-LH	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFL-LH	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP-SECONDARY - FFL-RH	6	1	J
G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2	EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010	Вилочный погрузчик с ДВС	Engine 4 Ton GAS	FRONT END	Mast	LIFT GP - STD-LH	7	1	J
GC15S2/GC18S2, GC20SC2	EM0CZ, EM0D1 \| SB1011	Вилочный погрузчик с ДВС	Engine 1 Ton GAS CUSHION	CHASSIS	Chassis	CYLINDER,STEERING;P/S	12	2	J
G20P3/G25P3/G30P3/G32P3/G33P3	EM0D2, EM0DZ, EM0F4 \| SB1012-00	Вилочный погрузчик с ДВС	Engine 2 Ton GAS	CHASSIS	Chassis	CYLINDER GP	15	2	J
G20P3/G25P3/G30P3/G32P3/G33P3	EM0D2, EM0DZ, EM0F4 \| SB1012-00	Вилочный погрузчик с ДВС	Engine 2 Ton GAS	CHASSIS	Chassis	CYLINDER GP-STEER	15	2	J

Модель техники	D50S2/D60S2/D70S2, G35S/G40S/G45S, D35S/D40S/D45S, D50S/D60S/D70S, D35S2/D40S2/D45S2, D50C2, D40SC2/D45SC2/D50SC2, G35S2/G40S2/G45S2, G50C2, G40SC2/G45SC2/G50SC2, D20S3/D25S3/D30S3/D32S3/D33S3, G20E3/G25E3/G30E3/G32E3, GC20E3/GC25E3/GC30E3/GC32E3, GC15S2/GC18S2, GC20SC2, D100/D120, D150, G20S3/G25S3/G30S3, GC20S3/GC25S3/GC30S3, BC20S2/BC25S2/BC30S2, BC25SE2, B20S2/B25S2/B30S2, G20P3/G25P3/G30P3/G32P3/G33P3, D50/D60/D70, BC20S/BC25S, BC30S
Номер по каталогу	D184112
Бренд	DOOSAN
Система Doosan	Engine 6 Ton DIESEL, Engine 4 Ton GAS, Engine 4 Ton DIESEL, Engine 2 Ton DIESEL, Engine 2 Ton GAS, Engine 2 Ton GAS CUSHION, Engine 1 Ton GAS CUSHION, Engine 10 Ton DIESEL, Engine 15 Ton DIESEL, Electric 2 Ton CUSHION, Electric 2 Ton PNEUMATIC
Раздел Doosan	CHASSIS, FRONT END
Тип техники Doosan	Вилочный погрузчик с ДВС, Электропогрузчик
Серии Doosan	EM0BH, EM0EH \| A130012, EM0B1, EM0BQ \| A231095, EM021, EM0BP \| D150864, EM0C1 \| A130013, EM0C9, EM0E8 \| A231526, EM0CB, EM0E9, EM0G2, EM0G3 \| SB1010, EM090, EM0GU \| A211796, EM0CW, EM0CX, EM0DX, EM0G9, EM0GA \| SB1008-00, EM0CU, EM0CV, EM0DY \| SB1009, EM0CZ, EM0D1 \| SB1011, EM083, EM084, EM0F1, EM0F2 \| A141520, EM086, EM0F3 \| A142307, EM097, EM099 \| A211798, EM094, EM095 \| A211800, EM0CJ, EM0CK, EM0CL, EM0CM, EM0CN, EM0CP, EM0CQ \| D290559, EM0B8, EM0B9, EM0BA, EM0BB, EM0BC, EM0BD \| SB1003, EM0D2, EM0DZ, EM0F4 \| SB1012-00, EM023 \| D170122, EM027, EM028, EM029, EM030, EM031, EM032 \| D270467
Узел Doosan	Chassis, Mast, Attachment, Carriage
Позиция на схеме Doosan	5, 6, 7, 8, 12, 15
